Moduly Nodz 12.5 kWh Plug‑and‑Play Energy Storage System

Engineered for maximum energy independence, the Moduly 12.5 kWh system delivers extended backup, peak‑shaving, and seamless solar integration—DIY installation in under 25 minutes.

Features:

• Maximum Capacity – Store 12.5 kWh to power large loads and long outages.
• Extended Peak‑Hour Cycle – 1.8 kW for up to 6 hours (≈ 10.8 kWh usable).
• Peak‑Shaving Power – Reduce peak demand fees by up to 30%.
• Integrated AI – Automated, real‑time energy optimization.
• Solar‑Ready – Plug directly into existing PV systems without extra inverters.
• DIY Installation – Set up in minutes, no electrician required.
• Flexible Financing – Subscription plans from $191/mo with zero upfront cost.

Ideal for:

• Large homes or multi‑family properties with significant energy demands.
• Off‑grid applications and extended outage scenarios.
• Commercial sites requiring reliable, high‑capacity backup.

• Solar Integrators maximizing self‑consumption and ROI.

Stay powered through any challenge with Moduly’s highest‑capacity system.

Performance Specs

• Max Output Current 15 A @12 0VAC (60 Hz)
• On-Grid Power 2 kW
• Backup Power 2 kW/ 4k W peak
• Energy Capacity 2.5 kWh up to 12.5 kWh

Off-grid inverter / UPS

• Rated power 2000 W
• Peak power 4000 W
• Input voltage range 20 - 31 V
• Output voltage 110 VAC ± 5%
• Output frequency 60 Hz ± 0.5 Hz
• Output waveform Pure Sine Wave
• Operating temperature -14 °F to 122 oF (-10 °C to 50 °C)


Protection function

• Low voltage, Over voltage, Overload,
• Over temperature, Short circuit, Input
  reverse polarity (burn fuse)
• Grid-tie inverter
• Rated power 1800 W
• Input voltage range 20 - 45 VDC
  Output voltage 120 VAC
• Output frequency 50 Hz/60 Hz (Auto control)
• Output current 15 A at 120 VAC
• Power factor >97.5%
• THD <5%
• Phase shift <2%
• Output waveform Pure Sine Wave
• Operating temperature -13 °F to 158 oF (-25 °C to 70 °C)


Protection function

• Islanding; Short-circuit; Low
  Voltage; Over Voltage; Over
  Temperature Protection

Mechanical Specs

12.5 kWh Nødz

• Size: 69 cm x 20 cm x 147.1 cm (27.2 in x 7.9 in x 58 in)
• Weight: 418.1 lbs (189.8 kg)


Moduly Controller

• Size: 69 cm x 20 cm x 27.5 cm (27.2 in x 7.9 in x 10.8 in)
• Weight: 56.2 lbs (25.5 kg)

Moduly Battery

• Size: 69 cm x 20 cm x 21.8 cm (27.2 in x 7.9 in x 8.6 in)
• Weight: 70.7 lbs (32.1 kg)

Legs

• Size: 42.3 cm x 18 cm x 10.6 cm (16.7 in x 7.1 in x 4.2 in)
• Weight: 8.4 lbs (3.8 kg)

Battery specifications (per module)

• Battery chemistry LiFePO4
• Nominal voltage 25.6 V
• Voltage range 17.6 V - 29.2 V
• Nominal capacity 96 Ah/2.46 kWh
• Charging current Standard 0.2 C(19 A)/Rapid 0.5 C(48 A)
• Max continuous
  discharge current 100 A
• Operating temperature 32 °F to 113 oF (0 °C to 45 °C)


BMS protection function

• Over-discharge, Overcharge, Short
  circuit, Temperature protection,
  Overcurrent protection


Battery charger

• Maximum output voltage 29.2 ± 0.2 VDC
• Nominal output power 800 W
• Input voltage 100 - 240 VAC 50 Hz/60 Hz
• Maximum input current 15 A (AC)
  Operating temperature 14 °F to 122 oF (-10 °C to 50 °C)
• Protection function Over voltage, Over temperature, Short circuit, Input reverse polarity


Safety and compliance

• Controller Certifications UL 2054, UL 62368-1, CAN/CSA C22.2 No. 62368-1:19, IEEE 1547
• Battery Certifications ANSI/CAN/UL 1973, FCC Environmental (for battery) California Prop 65, Transportation UN 38.3
• Protection Anti-islanding
